Hj92n Wave Spring Balanced Seal Food mechanical seal

Brand Name : JG

Model Number : HJ92N

Certification : FDA certificate

Place of Origin : Zhejiang, China

MOQ : 1pcs

Price : USD

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 1000PCS

Delivery Time : 3~10DAYS

Packaging Details : white box

Size : 18~100mm

HS code : 8484200090

Pressure : 0.2~2.5Mpa

Temperature : -50°C to +220°C

Speeds : 10m/s

Metal parts : SS304,SS316,904L, Titan

Application : Food mechanical seal

Product name : Wave Spring Balanced Seal

Contact Now

Hj92n Wave Spring Balanced Seal Food Mechanical Seal

The Hj92n Wave Spring Balanced Seal Food Mechanical Seal is a top - notch solution for the food processing industry. Engineered with advanced techniques and high - quality materials, it can handle up to 1.7 MPa pressure, operate at 25 m/s, and endure - 20°C to + 200°C. Its wear - resistant rotary ring, high - hardness stationary ring, food - grade secondary seal, and corrosion - resistant spring components ensure reliable, contamination - free operation. The easy - install and uninstall design simplifies maintenance, and it's compatible with various food - grade media, making it a reliable and versatile choice for food - processing applications.

Our product including:

1: mechanical seals for water pump: equivalent with John Crane and Burgmann Seal, etc

2: mechanical seals spare parts: made to order Silicon Carbide, sintered silicon carbide seal rings, graphite carbon seal rings ,tungsten carbide seal rings, O rings, springs, CNC machining service.

Operating Limits

Item
Details
Pressure
≤1.7MPa
Speed
≤25m/s
Temperature
-20℃~+200℃
Rotary Ring
Carbon/Sic/TC
Stationary Ring
99% Ceramic/Sic/TC
Secondary Seal
VIT/NBR/EPDM
Spring and Other Parts
SUS304/SUS316

Specifications

Item
Details
Rotary ring
silicon carbide, carbon
Secondary seal
NBR, EPDM, FKM, PTFE. PTFE secondary seals variant for high chemical resistance
Spring and parts
SS304, 316. Easy to install and uninstall

Application Range

Item
Details
Pressure in the seal chamber
0 - 1.2MPa
Temperature in the seal chamber
-30ºC - 180ºC
Linear Velocity
≤ 10m/s
Medium
water, oil and minor corrosive liquid

The direction of rolling: looking from the stationary face,if the pivot be rolled in clockwise direction,spring should be in right direction rolling.

Chemical industry
Pulp and paper industry
Water and waste water technology
Sugar industry
Low solids content media
Cooling water pump
Basic sterile application

Advantages:

◆ For extreme temperature ranges
◆ No dynamically loaded o ring
◆ Very good self c;eaning effect
◆ Suitable for low-end srerile applications

Shipping & Payment Terms:

Port of Loading: Shanghai

Shipping Method: DHL,UPS,FEDEX,TNT, etc

Payment Terms: T/T, Western Union, money gram

Our services:

◆ OEM/ODM orders are available for our factory

◆ Accept customized mechanical seals according to your drawing or requirements

◆ Small quantity is accepted

◆ Provides excellent quality with competitive price

Hj92n Wave Spring Balanced Seal Food mechanical sealHj92n Wave Spring Balanced Seal Food mechanical sealHj92n Wave Spring Balanced Seal Food mechanical sealHj92n Wave Spring Balanced Seal Food mechanical seal
